2-CH Wall Amplifier

  • Adopt Bluetooth wireless connection technology
  • Standard 86 Mounted on the wall for easy control
  • RS485 integration with third party system
  • Support audio input function with secure and fast connect phoenix connectors
  • Suitable for hotels, villa, homes, commercial areas, kid’s room, etc.
Model BA-220DH
Output Power 2*20W
Speaker Impedance 8ohm
Bluetooth Wireless Range ≤10M
Frequency Response 20Hz-20KHz
Music format Mp3, WMA, WAV, AAC, WAW, APE, etc.
Power Requirements 90-250VAC
Color Grey color default, black optional
Product Dimension 86x86x42mm
Back Box Dimension 86x86x56mm
Net Weight 132g

Download

BA-220DH

×
