- Public Address and Commercial Audio Systems
Features:
● Paging up to 10 speaker zones
● With 10 try contact in and out
● Built-in pleasant chime
● With 1 mic, 2 aux and 4 remote paging microphone inputs
● 4 priority levels MIC1 highest priority to EMC MIC, remote paging MIC and aux as last
● LED indicator for all the zones
| MODEL | AL-10P |
| MIC Input | 600 Ohm 5mV, unbalanced |
| Line Input | 10K Ohm, bigger or equals to 220mV unbalanced |
| Line Output | Bigger than 775mV at 0dB, unbalanced |
| Frequency Response | MIC:100Hz – 15KHz; Line: 60Hz – 15KHz at +/-3dB |
| S/N Ratio | Better than 70dB |
| THD | Less than 0.01% at 1KHz |
| Protection | AC Fuse: 0.5A |
| Mute Attenuation | Line1 and MIC mute Line2 at 0~30dB |
| Power Requirement | 220~240V AC, 50/60Hz |
| Dimensions | 89(H) x 483(W) x 366(D) mm |
| Built-in Dimensions | 2U rack 19 inch |
| Net Weight | 6.40kg |
