All-in-one Mixer Power Amplifier with Dante and DSP

Description

The MA-2300V2+/MA-2300DV2+ is a all-in-one DSP amplifier featuring 16 inputs and 10 outputs, designed for high-quality sound reinforcement in a variety of settings, such as medium to large conference rooms, courts, auditoriums, and multi-functional halls. This unit integrates advanced DSP technologies, including feedback suppression, AI noise cancellation (ANC), echo cancellation (AEC), automatic gain control (AGC), auto mixing, matrix mixing, equalization, crossover, delay, compressor, and limiter.

Features

• TCP/IP network control for managing multiple devices
• Supports multiple control methods: TCP/IP, RS232, RS485, USB
• Support computer software control
• Supports both playback and recording through stereo USB soundcard transmission
• Built-in Bluetooth technology for wireless streaming
• 48V phantom power on Input Channels
• With color LCD display, allowing easy configuration of device name, presets, IP settings and input/output volume
• Easily switch between Free Matrix and Bridge Mode for flexible audio routing and management.
• Supports camera tracking with PELCO-D, PELCO-P, and VISCA protocols, enabling automatic camera control based on voice activation.
• Save and recall up to 60 preset configurations for quick setup and adjustments.
• Seamlessly integrates with up to four WM-2300U true diversity wireless handheld microphones for versatile sound reinforcement(optional)Lucky Tone MA-2300V2+ MA-2300DV2+ WM-2300U datasheet 20241230
