SIP-T06 provides complete desk phone solutions with flexible functionality, HD Voice Quality, and highly easy operation. It is absolutely an excellent Smart Video Phone for small to large sized business, as well as mission-critical Enterprise Business.
Features
Support 6 SIP lines, 3-way conferencing
POE enabled, optional external power supply
Support Handset / Hands-free / Headset mode
Supports third party communication APP
Full Programmable DSS Keys and soft function Keys
DSS can support up to 140 Stations
Online recording & message forwarding
Call conference enhancement
Flexible dial plan with auto provision
Support LDAP & XML phone book
High Interoperability – Compatible with major platforms: 3CX, Asterisk, Broadsoft, Elastix, Zycoo, etc.
| MODEL | SIP-T06 |
| Networking | 10/100/1000Mbps Ethernet, dual bridged port for PC bypass |
| IP Configuration | Static / DHCP / PPPoE |
| Protocols | SIP2.0 over UDP/TCP/TLS; RTP/RTCP/SRTP; STUN; DHCP; LLDP; PPPoE; 802.1x; L2TP; OpenVPN; SNTP; FTP/TFTP; HTTP/HTTPS; TR-069 |
| Physical Ports | |
| RJ9 Port x2 | Handset x1, Headphone x1 |
| RJ45 Port x2 | Network x1, PC x1 (Bridged to Network) |
| HDMI Port x1 | Type A |
| USB 2.0 Port x2 | Mini-B x1, Connect with Flash Driver Standard A x1, Connect with BT USB dongle or Flash Driver |
| TF card slot x1 | TF Card Support Up to 32G |
| Keypad | 5 keys (Headset, Menu, Hands-free, Back, Home) |
| Screen | 7 inch (800×480) capacitance color-screen LCD |
| Operation System | Android 4.2.2 OS |
| Video Format | MP4/3GP/FLV |
| Video CODEC | H.263/H.264 |
| Bandwidth Selection | 64kbps~4Mbps |
| Frame rate Selection | 10~30fps |
| Audio format | WAV/MP3/OGG |
| Narrowband CODEC | G.711a/u, G.723.1, G.729AB, AMR, iLBC |
| Wide band CODEC | G.722 |
| Image format | JPEG/PNG/BMP/GIF |
| Installation | Desktop Stand or Wall-mount |
| DC Power Input | 12V/1A |
| Power Consumption | Idle 2.5W/Active 5W |
| Dimensions | Desktop Stand (angles 1): 254.8×154.9×202.8mm Desktop Stand (angles 2): 254.8×167.8×182.4mm Wall-mount: 254.8×118.4×206.9mm |
| Gift Box Dimensions | 290x260x73mm |
| Outer CTN Dimensions | 540x385x310mm (10 PCS) |
