- Public Address and Commercial Audio Systems
Features:
● Ranging from 1000W to 1500W power capacity
● Reliable and mature technology prevent device from overheat
● Selectable output: 100V, 70V and 4-16 Ohm
● Loudspeaker output with short circuit protection
| MODEL | D-AMP1000 | D-AMP1500 |
| Rated Power Output | 1000W | 1500W |
| Output Regulation | Less than 3 dB (no load to full load) | |
| Speaker Output | 4.9 ohms (70V), balanced | 3.3 ohms (70V), balanced |
| 10.0 ohms (100V), balanced | 6.7 ohms (100V), balanced | |
| Low impedance: 4-16 ohms, balanced | Low impedance: 4-16 ohms, balanced | |
| Input | Less than 1V, unbalanced, XLR and phone jack | |
| Output | 775V, 0dB, XLR and phone jack | |
| Frequency Response | 50 – 18,000 Hz, +/- 1.5dB | |
| THD | Less than 0.5% at 1KHz (1/3 Rated Power) | |
| S/N Ratio | Better than 105dB | |
| Slew Rate | 40V/Us | |
| Controls | Volume control and power switch | |
| Cooling | Internal 12VDC fan, extensive heat sinking | |
| Indicators | Power, Clip, Signal, Protect, and Temp LEDs | |
| Protection | AC Fuse: 20A | AC Fuse: 25A |
| Current limiter, short circuit and thermal protection circuits | ||
| Power Consumption | 1350W | 2000W |
| Power Requirement | AC 220V ± 10% 50-60Hz | |
| Dimensions | 133(H) x 486(W) x 483(D) mm | |
| Net Weight | 25.80kg | 25.80kg |
| Gross Weight | 28.10kg | 38.10kg |
