SIP Control Station With Touch Screen

With a 10/100M Ethernet interface, line input and output, SIPM30T is an SIP desktop intercom host that is used with SIP server.
SIPM-30T network paging microphone can perform point-topoint IP intercom and multicast to the IP terminal through a microphone or local line input.

As a host of the IP broadcast intercom system, SIPM-30T can be used in places where intercom, monitor and emergency alarms
are needed, such as control centers of self-service banks, interrogation rooms, classrooms, hospitals and parking lots.

As an intercom terminal, SIPM-30T supports full-duplex twoway intercom and has good echo suppression. We offer standard
sip mode, which can be used in other standard SIP systems and compatible with standard SIP terminal devices.

Features

Stand-alone intercom function
Stand-alone paging function
Stand-alone unicast and multicast functions
Support modify parameters directly on the mic
Play Audio from SD or USB to the zones

MODEL SIPM-30T
Network Communication Protocol SIP
Network Interface 10/100Base-TX,RJ45
Frequency and Sampling Rate 8kHz-32 kHz, 16 bit
Decoding MPEG,ADPC
Microphone Frequency Range 70Hz~12.5KHz
Operating Temp. 0~65°C
Screen 7” touch screen
Power Supply DC 12V
Dimension 250 x 145 x 55 mm
