- Public Address and Commercial Audio Systems
Features:
● 16 loudspeaker line selector
● Power handling of each zone achieve 1.5KW
● One audio input and one alarm input
● With ALL ON/OFF selector
| MODEL | D-ZS16 |
| Input | 70/100V audio signal |
| Output | Output maximum for each zone:150W |
| Priority Bus | 16 channels activated by 0V signal |
| Power Handling | 1.5KW total capacity |
| Alarm Output | 0V signal |
| Controls | 16 pushbutton zone selectors, 1 power switch |
| Power Supply | AC 220V ± 10% 50-60Hz;24VDC |
| Dimensions | 89(H) x 483(W) x 350(D) mm |
