Power Amplifier

Features:
●  Ranging from 360W to 660W power capacity
●  Reliable and mature technology prevent device from overheat
●  Selectable output: 100V, 70V and 4-16 Ohm
●  Loudspeaker output with short circuit protection

MODEL D-AMP360 D-AMP460 D-AMP660
Rated Power Output 360W 460W 660W
Output Regulation Less than 3 dB (no load to full load)
Speaker Output 13.6 ohms (70V), balanced 10.7 ohms (70V), balanced 7.4 ohms (70V), balanced
27.8 ohms (100V), balanced 21.7 ohms (100V), balanced 15.1 ohms (100V), balanced
Low impedance: 4-16 ohms, balanced Low impedance: 4-16 ohms, balanced Low impedance: 4-16 ohms, balanced
Input Less than 1V, unbalanced, 10K ohm, XLR and phone jack
Output 10K ohm, 0.775V, 0dB, XLR and phone jack
Frequency Response 60 – 15,000 Hz, +/- 3dB
THD Less than 0.5% at 1KHz (1/3 Rated Power)
S/N Ratio Better than 70dB
Slew Rate 15V/Us
Controls Volume control and power switch
Cooling Internal 12VDC fan, extensive heat sinking
Indicators Power, Clip, Signal, Protect, and Temp LEDs
Protection AC Fuse: 10A AC Fuse: 12A AC Fuse: 15A
Current limiter, short circuit and thermal protection circuits
Power Consumption 485W 620W 880W
Power Requirement AC 220V ± 10% 50-60Hz
Dimensions 133(H) x 496(W) x 483(D) mm
Net Weight 15.50kg 18.10kg 20.1kg
Gross Weight 17.10kg 19.70kg 21.7kg 21.7kg
